Description

● 7 years Warranty for compressor and 5 years for parts to ease your worries
●Cool and heat multiple zones individually and efficiently
●6 modes and 5 fan speeds to customize your comfort
●Cool even at 125℉ heat even at -13℉
●Stay connected and in control with the Wifi-enabled feature
●Remote control with digital display for easy operation
●Advanced inverter technology enhances energy efficiency
●Low noise operation ensures a peaceful environment
●Chassis heating function prevents freezing on cold days
●24H timer provides programmable convenience
●Removable and washable filter for hassle-free maintenance
●R32 refrigerant has a lower environmental impact
●Complies with Energy Star AHRI and ETL

● Multi-room Cooling Solution: Designed to cool any corner of your home this 30000 BTU 4 zone mini split air conditioner can independently adjust the temperature to meet the individual needs of different rooms. The chassis heating function maintains the normal operation of the outdoor unit enabling it to withstand any climate conditions (-13℉~125℉).
● Less Energy Consumption Lower GWP: This energy star certified mini split ac features an innovative inverter technology operating at a remarkable 23 SEER2 rating and 10 HSPF2 rating. The use of R32 refrigerant brings you a greener lifestyle. Moreover it is also certified by ETL and AHRI.
● Multiple Functions and Modes: This ductless mini split air conditioner offers 6 modes (auto/cool/heat/dry/fan/sleep) and 5 wind speeds (auto/low/mid/high/strong) for you to choose from. Other features such as auto swing feeling and health extend comfort to daily use.
● Smart Control Smart Life: You can easily adjust settings monitor performance and control your AC from anywhere via your smartphone or the remote control. In addition the 24-hour timer allows you to plan your climate control around your schedule conveniently.
● Low Noise and Easy Maintenance: With the quiet sleep mode and screen off function you can enjoy a restful night. In addition the filter can be easily removed and cleaned. Please note: A professional HVAC installer is required.

Please note that the power cord is not included

• Color: White
• Material: Metal Aluminum Plastic
• Indoor Unit Dimensions:
• 7000 BTU: 31" x 11.5" x 7.8"(L x W x H)
• 9000 BTU: 31" x 11.5" x 7.8"(L x W x H)
• 12000 BTU: 34.5" x 11.7" x 7.6"(L x W x H)
• 17000 BTU: 38.8" x 12.4" x 8.9"(L x W x H)
• 24000 BTU: 44.1" x 13" x 9.1"(L x W x H)
• Outdoor Unit Dimensions:
• 18000 BTU: 34.7" x 13.9" x 21.9"(L x W x H)
• 30000 BTU: 41.2" x 17.9" x 31.8"(L x W x H)
• 36000 BTU: 41.2" x 17.9" x 31.8"(L x W x H)
• Multi Zone Combination: 4
• Power Supply: 208-230V~60Hz/1PH
• Temperature Setting Range: 60℉~90℉
• Refrigerant: R32
• Heat Pump of 7k: 0.6 Ton
• Heat Pump of 9k: 0.75 Ton
• Heat Pump of 12k: 1 Ton
• Heat Pump of 17k: 1.5 Ton
• Heat Pump of 24k: 2 Ton
• Dehumidifying Capacity of 7k: 35.5 Pints/Day
• Dehumidifying Capacity of 9k: 35.5 Pints/Day
• Dehumidifying Capacity of 12k: 51 Pints/Day
• Dehumidifying Capacity of 17k: 81 Pints/Day
• Dehumidifying Capacity of 24k: 130 Pints/Day
• SEER2 of 18k: 22
• SEER2 of 30k: 23
• SEER2 of 36k: 23
• HSPF2: 10
• Indoor Unit Noise Level of 7k: 30 dB
• Indoor Unit Noise Level of 9k: 30 dB
• Indoor Unit Noise Level of 12k: 32 dB
• Indoor Unit Noise Level of 17k: 35 dB
• Indoor Unit Noise Level of 24k: 40 dB
• Net Weight of Outdoor Unit 18k: 75 lbs
• Net Weight of Outdoor Unit 30k: 149 lbs
• Net Weight of Outdoor Unit 36k: 154 lbs
• Net Weight of Indoor Unit 7k: 17.5 lbs
• Net Weight of Indoor Unit 9k: 17.5 lbs
• Net Weight of Indoor Unit 12k: 20 lbs
• Net Weight of Indoor Unit 18k: 26.5 lbs
• Net Weight of Indoor Unit 24k: 31 lbs
• Box Qty: 5
• Package Includes:
• 1 x Outdoor Unit
• 3 x Indoor Unit
• 3 x Communication Wire
• 3 x Copper Connection Pipe (Air + Liquid)
• 3 x Drain Hose
• 3 x Remote Control
• 3 x Mounting Plate
• 3 x Wall Sleeve
• 6 x Wall Cap
• 3 x Screw Kit
• 6 x Putty
• 6 x Tape
• 4 x User Guide

Specifications

• Usage: Indoor & outdoor
